Ceramic Flexible HVAC Differential Pressure Transmitter Safety For Equipment Protection
  • name
  • name
  • name
  • name

Ceramic Flexible HVAC Differential Pressure Transmitter Safety For Equipment Protection

Brand Name: SongFast
MOQ: 500pcs
Price: $5.30 - $6.50/pieces
Packaging Details: According to customer requirements
Payment Terms: T/T
Detail Information
Product Description
Detail Information
Place of Origin:
Dongguan,China
Certification:
ISO 9001, IATF 16949
Document:
200 Series Pressure Transmi...r.docx
Pressure Type:
Gauge Pressure, Negative Pressure, Absolute Pressure
Range:
≤±1%F.S；Customizable
Housing Materials:
SUS304 Stainless Steel (standard),Copper (optional), 316Lstainless Steel (optional), Customizable
Sensor Materials:
Ceramic (Standard)
O-ring Materials:
NBR (Standard), PTFE/CR/EPDM (Optional)
Cable Materials:
RVVP2×0.35mm² PVVP3×0.35mm²
Pressure Connection:
Thread Specifications Can Be Customized According To Customer Requirements
Protection Rating:
IP65、IP67、Customizable
Long-term Stability:
0.1%F.S.±0.05%/year
Insulation Resistance:
>100M Ω @50V DC
Supply Ability:
10000pcs/month
Highlight:

Ceramic HVAC Differential Pressure Transmitter

,

Flexible HVAC Differential Pressure Transmitter

,

Safety Air Conditioner Pressure Transducer

Product Description
Ceramic Flexible HVAC Differential Pressure Transmitter
Advanced ceramic sensor technology and flexible refrigeration HVAC pressure sensor designed for industrial applications and equipment protection.
Key Features
  • Wide Operating Temperature Range: Functions seamlessly in environments from -40℃ to 85℃
  • Compact and Cost-Effective Design: Optimized for high performance at an economical price
  • Advanced Compensation Technology: Employs algorithm-based correction for enhanced precision
  • Exceptional Overload Resistance: Handles up to 150% of full-scale overload with ease
  • High Durability: Engineered to endure harsh and demanding conditions
  • Flexible Output Options: Provides a variety of signal outputs for diverse application needs
  • Customizable Solutions: Offers tailored configurations to meet specific operational requirements
Applications
  • Water Resource Management
  • Process Equipment Monitoring
  • Mechanical Manufacturing
  • Petrochemical Industry
  • Food and Pharmaceutical Processing
Product Overview
The 200 Series Transmitter is a cutting-edge, independently developed device, purpose-built for a wide range of industrial pressure measurement applications. At its core is a proprietary ceramic sensor, which delivers exceptional resistance to temperature fluctuations and corrosive environments, ensuring long-term stability and dependability.
Its compact form factor and robust performance make it ideal for monitoring both liquids and gases in industrial settings. This transmitter is particularly suited for use in hydraulic energy systems, process equipment, machinery manufacturing, the petrochemical sector, and the food and pharmaceutical industries.
Our meticulous production processes—from R&D and assembly to calibration and quality inspection—adhere strictly to international quality management standards, ensuring consistent performance and reliability.
Ceramic Flexible HVAC Differential Pressure Transmitter Safety For Equipment Protection 0 Ceramic Flexible HVAC Differential Pressure Transmitter Safety For Equipment Protection 1
Technical Specifications
Model200 Series
Pressure TypeGauge Pressure, Negative Pressure, Absolute Pressure
Range-1-0-1…600 bar (Customizable)
Accuracy≤ ±1%F.S；Customizable
Electrical Performance2-wire | 3-wire | 4-wire
Output Signal4~20mA | 0.5~4.5V | 0.35~2.7V Ratio | 0.132~4.5V Ratio | IIC/UART Digital Signal
Supply Voltage8-32V DC | 5V DC | 3-5.5V DC/5VDC
Operating Temperature-40℃~85℃
Storage Temperature-40℃~105℃
Electrical ConnectionPackard Connector, Straight Connection, Aviation Connector, Hirschmann Connector
Pressure ConnectionInternal Thread | 7/16~20 UNF
External Thread | 1/4" NPT,R1/4,G1/4",G1/2",M14×1.5,M16×1.5,M20×1.5
Customizable | Thread specifications can be customized according to customer requirements
MaterialsHousing | SUS304 stainless steel (standard),Copper (optional), 316L stainless steel (optional), Customizable
Sensor | Ceramic (Standard)
O-ring | NBR (Standard), PTFE/CR/EPDM (Optional)
Protection RatingIP65,IP67,Customizable
Response Time≤10ms
Overload Pressure150%F.S.
Long-term Stability0.1%F.S.±0.05%/year
Burst Pressure300% F.S. (P ≤100bar); 200% F.S. (100bar＜P ≤400bar); 150%F.S(400＜P ≤600bar)
Insulation Resistance>100M Ω @50V DC
Dimensions and Wiring Definitions
Ceramic Flexible HVAC Differential Pressure Transmitter Safety For Equipment Protection 2
Wiring Definitions
Ceramic Flexible HVAC Differential Pressure Transmitter Safety For Equipment Protection 3
Ordering Guide
Ceramic Flexible HVAC Differential Pressure Transmitter Safety For Equipment Protection 4
Frequently Asked Questions
What makes Songfast's products stand out from competitors?
Our technical team boasts over 20 years of experience in the sensor industry. We provide rapid, professional solutions tailored to customers' application scenarios and welcome personalized customization requests. Additionally, our dedicated production quality management team ensures strict quality control while delivering goods within a 30-day lead time.
What official certifications and industry compliance standards has the company obtained?
Our certifications include:
  • ISO 9001
  • IATF 16949 (automotive)
  • ISO 45001 (safety)
  • ISO 14001 (environmental)
We also hold over 20 national patents.
Do you offer custom development for new products beyond your website offerings?
Yes, our company provides custom development services to meet specific customer needs.
