Flush Diaphragm Ceramic Diaphragm Pressure Transmitter For Industrial Control And Monitoring

Brand Name:	SongFast
MOQ:	500pcs
Price:	$1.90 - $2.90/pieces
Packaging Details:	According to customer requirements
Payment Terms:	T/T

Detail Information

Product Description

Detail Information

Place of Origin:

Dongguan,China

Certification:

ISO 9001, IATF 16949

Document:

RS123A 12×12mm Flush Diaph...r.docx

Supply Voltage:

2-30V DC

Bridge Impedance:

※10.0KΩ±30%

Sensitivity:

※2.0-4.0mV/V/FS

TCR:

≤100ppm/℃@-40℃~125℃

Offset:

※0±0.4mV/V

Operating Temperature:

-40℃~135℃

Storage Temperature:

-40℃~150℃

Thermal Offset/span Shift:

※Tco&Tcs 0.02%FS/℃ Max

NonLinearity:

0.25%FS Max

Hysteresis&Repatability:

0.25%FS Max

Response Time:

＜2mS

Dielectric Strength:

>2KV

Supply Ability:

10000pcs/month

Highlight:

Industrial Monitoring Ceramic Diaphragm Pressure Transmitter

Industrial Control Ceramic Diaphragm Pressure Transmitter

Flush diaphragm Industrial Pressure Transmitter

Product Description

Flush Diaphragm Ceramic Diaphragm Pressure Transmitter

High-performance pressure sensor core designed for industrial control and monitoring applications requiring precision and reliability.

Main Features

Patented circuit layout design
Unique structural design
Ultra-high overload and burst pressure capability for high-impact scenarios
Wide operating temperature range for broad applicability
High-elasticity diaphragm for enhanced sensitivity and high-precision measurement
Supports precise data acquisition

Product Parameters

Series Name	RS123 Series
Type	Flush diaphragm
Size (Length × Width × Height)	12×12×3.0mm
Supply Voltage	2-30 V DC
Bridge Impedance	5.0kΩ ± 30%
TCR	≤ 100 ppm/℃ @ -40℃~135℃
Operating Temperature	-40℃~135℃
Storage Temperature	-40℃~150℃
Temperature Drift	Tco & Tcs 0.03%FS/℃ Max / Tco & Tcs 0.05% FS/℃ optional
Nonlinearity	0.25% FS Max
Hysteresis & Repeatability	0.25% FS Max
Zero Offset	0±0.4mV/V
Sensitivity	2.0-4.0mV/V, Typ: 3.0mV/V/FS
Response Time	＜ 2mS
Insulation Resistance	＞ 2KV
Zero-point Long Term Stability @25℃	Zero@25℃: ＜0.25 FSO (no time accumulation)
Cycle Life	5 million pressure cycles @ 2-5Hz, 0~full scale pressure~0, 15~35℃

Product Range - RS123A Series (12×12×3.0mm)

Product Model	Working Pressure Range	Pressure Type	Overload Pressure	Burst Pressure
RS123A005C	0-5 Bar	Gauge	＞ 15 Bar	＞ 25 Bar
RS123A010C	0-10 Bar	Gauge/Sealed Gauge	＞ 25 Bar	＞ 40 Bar
RS123A020C	0-20 Bar	Gauge/Sealed Gauge	＞ 40 Bar	＞ 60 Bar
RS123A030C	0-30 Bar	Gauge/Sealed Gauge	＞ 60 Bar	＞ 100 Bar
RS123A050C	0-50 Bar	Sealed Gauge	＞ 100 Bar	＞ 150 Bar
